The factory Bronco Raptor airbox is built to be quiet, not to flow. Ford put baffles in it specifically to muffle the twin turbos, and the filter is sized for a service interval rather than for airflow. On a 3.0L EcoBoost that is being asked to move nearly 6,000 lb of truck, that is the wrong set of priorities.
The S&B intake is a full system rather than a drop-in filter. You get an oversized airbox, a large filter, high-flow tubes that run all the way to the turbo inlets, a silicone front air scoop, and a snap-in clear lid. S&B lists it at up to 41.91% improved airflow over stock with around 99% filtration efficiency, which is the combination that matters on a truck that spends time in dust.
S&B Bronco Raptor Intake Overview
Replacing only the filter leaves the restriction in place, because the restriction is the box and the tubes. S&B's approach is to open the whole path: more inlet area at the scoop, more filter media area inside a bigger box, and smoother routing to the turbos.
For a Raptor owner that shows up three ways. Response sharpens because the turbos see less resistance. The turbos get audibly louder, because the factory baffles that were quieting them down are gone. And the engine bay looks like someone deliberately built it rather than left it alone.
Cotton Cleanable vs Dry Extendable
Same intake system, two filter choices. The right answer depends entirely on how you use the truck, not on which one flows more on a bench.
Clean, re-oil, reuse
Needs S&B cleaning and oil products
For owners who don't mind servicing a filter
Easier maintenance routine
Better suited to dusty trails and daily use
No risk of over-oiling
How to Choose
- Pick the cotton cleanable (75-5168) if you want maximum airflow and you are comfortable cleaning and re-oiling a filter on schedule with the correct products.
- Pick the dry extendable (75-5168D) if the truck sees dusty trails, gets daily driven, or you would simply rather never deal with filter oil. Nothing to over-apply, nothing to migrate downstream.
Key Features
- Large front air scoop. A larger than stock silicone scoop that feeds more cool air into the airbox instead of pulling from under the hood.
- Massive airbox and filter. The oversized box and large filter cut restriction while shielding the media from engine bay heat and debris.
- High-flow intake tubes. Routed all the way to the turbo inlets for a smoother, less restrictive path.
- Snap-in clear lid. Pop it off to inspect the filter. No handful of lid screws to keep track of.
- Premium silicone components. Scoop, coupler, tube seal, and filter-related pieces are silicone, which resists heat and cracking better than plastic.
- More turbo sound. S&B removes the restrictive factory baffles, so the intake and turbos are noticeably louder under throttle. For most Raptor owners this is the point.
Install Resources
This is a straightforward bolt-on. S&B lists approximate install time at about 1 hour using common hand tools most gearheads already own: 7mm, 8mm, and 10mm sockets with extensions, a 3/4-inch wrench, a nut driver, a panel popper, a screwdriver, wire cutters, and pliers.
S&B maintains digital step-by-step instructions for this kit, and they keep them current in a way a printed sheet in a box never is.
Frequently Asked Questions
Does the S&B Bronco Raptor intake fit the 3.0L EcoBoost?
Yes. This intake is designed for the Ford Bronco Raptor with the 3.0L EcoBoost. S&B currently lists fitment for 2022-2026 Bronco Raptor models. Verify fitment before ordering.
What is the difference between the 75-5168 and the 75-5168D?
The 75-5168 uses S&B's oiled Cotton Cleanable filter, which you clean and re-oil. The 75-5168D uses the Dry Extendable filter, which requires no oil at all. Same intake system otherwise.
Does the S&B Bronco Raptor intake require a tune?
No tune is typically required for an intake upgrade like this. That said, tuning is how you get the most out of supporting modifications if you are building a more aggressive Raptor.
Will the S&B intake make my Bronco Raptor turbos louder?
Yes. The kit removes the restrictive factory baffles that quiet the turbo system, so expect noticeably more intake and turbo noise under throttle.
How long does the S&B Bronco Raptor intake take to install?
S&B lists approximate install time at about 1 hour.
What tools do I need to install the S&B intake?
Basic hand tools: 7mm, 8mm, and 10mm sockets with extensions, a 3/4-inch wrench, a nut driver, a panel popper, a screwdriver, wire cutters, and pliers.
Can I install the S&B Bronco Raptor intake at home?
Yes. Most enthusiasts with basic tools can do this in a driveway by following S&B's digital instructions.
Is the S&B intake good for off-road use?
Yes. The enclosed airbox, large filter, and silicone components make it a strong choice for owners who split time between pavement and trail. If you spend real time in dust, the dry extendable filter is the easier one to live with.
