Wagner Tuning Competition Intercooler Kit EVO 2 Audi RSQ3 - 200001082
Competition Intercooler kit EVO2 for Audi RSQ3 8U
The high performance intercooler has the following core dimension (600mm x 260 mm x 100mm) and thus offers a 87% larger cooling surface and 70% more charge air volume compared to the original intercooler. The newly developed Competition Core granted the adjacent components, for example watercooler, sufficient airflow and is also very light. The endtanks of the intercooler are made ??of cast aluminum and have been optimized under flow analyzes in the CAD system. With the help of additional air baffles, inside inlet, providing for a uniform filling of the intercooler. The result is excellent cooling properties with minimum back pressure. So this kit is just the right thing for racing. The intercooler and the original crossmember form a stable unit and weighs only 11.2 kg. It is mounted to the original mounting points and is easy to perform (1:1 exchange). Optimum cooling of the charged air with a clear increase in performance! 66mm In and Outlet
OEM intercooler: cooling surface 832cm² / charge air volume 9,15L
WT EVO 2 Competition: cooling surface 1560cm² / charge air volume 15,6L
packing list:
1 intercooler including crossmember
1 mounting material
1 installation instruction
Comment:
only for racing
Fitment - Audi RSQ3 8U 2.5 TFSI
