The Power By The Hour Performance Gen 1 body harness has been updated. The PCP-1116B now not only allows easy integration of the 6R80 Automatic transmission, it also now is compatible with manual transmissions and independently controlled automatic transmissions as well. We added the needed wiring to ensure that if you are going manual or auto only one body harness is needed. Additionally, this harness is also compatible with use with all 2007-14 GT500 5.4L engines.
This is a great option for anyone purchasing used powertrains, crank a palet’s, and used engines. In most cases you receive the pcm, sensors, and pedal needed to run the engines but are missing the wiring. This harness will allow you to finish the job without having to purchase pricey control packs.
Key features of the PBH 6R80 Harness are below:
*labeled wiring leads for fuel pump, cooling fan, starter trigger, and battery power hookup
*OEM connectors
*select shift wiring for easy integration to aftermarket and custom shifters
*detachable fuse box
*works with 11-14 Mustang GT, F150, and GT500 PCM new or used.
*detailed instructions and oem function
*designed specifically for Coyote and GT500 powered projects
*no horsepower limitations
Compatibility:
*2011 2012 2013 2014 Coyote, Roadrunner, and F150 Coyote V8 engines
*2007 2008 2009 2010 2011 2012 2013 2014 GT500 V8 engines with 11-14 model engine harness only
*2011-newer Mustang 6R80 transmissions
*All manual transmissions
*All independently controlled or manually shifted automatic transmissions
*2011-up F150 6r80 transmissions
