This item is not compatible with BMR BK047 or BK048. Also if you are using the BMR CB005 Cradle Lockouts you must choose the option from the dropdown menu for the specific alignment kit that's for the CB005's.
2015-Present Rear Subframe Alignment Kit 25315. S550 Mustang’s subframe mounting holes are excessively large when compared to the bolts. Excessive clearance can cause issues with the subframe to crossemember alignment of up to .5150″ from side to side. An alignment issue can locate the crossmember in a cattywampus orientation. Potential issues with the 4 wheel alignment from the front to the rear suspension components can result from this excessive clearance.
J&M Products centering bushings part # 25315 are made from CNC machined 6061 billet aluminum, then Anodized to Mil A 8625 Type 2 specification for a clear corrosion resistant coating. CNC aluminum billet sleeves slide into the subframe holes that have a significant amount of clearance from side to side from the factory. Should you remove your crossmember from the subframe these bushings assure a proper alignment every time it gets bolted back in.
2015-Present Rear Subframe Alignment Kit 25315 Features and benefits:
Aligns subframe to crossmember every time!
Easy to install
No cutting or welding/fabrication skills necessary
Lifetime warranty
Uses the factory hardware
Lightweight billet 6061 aluminum for precision machining
No permanent modifications
Made in the USA
Anodized to Mil A 8625 Type 2 Specification for a clear corrosion resistant coating
Fire proof and heat resistant
