Fabtech 3.0Dl Bypass Rr 0-3" Raptor Pair Packaged - FTS22287
3.0DL BYPASS RR 0-3" RAPTOR PAIR PACKAGED
In-field testing and multiple vehicle fit checks ensure products will fit properly during installation and provide years of trouble free service with superior vehicle ride qualities.
2010-14 Ford F150 Raptor 4WD - Fits 0-2in Lifts. The factory rear Raptor shocks have something less than desired when it comes to damping in aggressive offroad conditions. Dirt Logic 3.0 Bypass shocks will improve the ride quality of the rear suspension for aggressive offroad driving along with a compliant highway ride. These Raptor Bypass shocks feature a 3 tube construction that provides two adjustments for compression and one for rebound. The tubes have been precisely placed on the body to provide superior damping throughout the travel range. Each Bypass tube adjuster comes preset from hours of testing for the best overall performance. This eliminates the need to spend time adjusting on your first drive. Just bolt them on and go hit the trail. The 2.5 OD piggyback reservoir provides additional cooling to help reduce fade during high speed offroad use. Each bypass tubes and reservoir port are meticulously TIG welded to the 3.0 steel body. The body is then pressure tested, honed and coated with a Cerakote finish in tactical black for extreme durability. This coating provides 120 hour salt spray compared to zinc plated steel shocks only going 48 hour salt spray. NitroSteel 7/8in piston rods are utilized for maximum corrosion resistance. A durable piston rod boot is included to totally protect the rod from sand and rock spray that can cause damage leading to seal failure. High tolerance internal components feature Viton seals and a 2.75in OD billet piston with variable flow bleed ports. It provides a compliant ride at low speed yet be able to handle big impact hits with ease. Completing the blacked out appearance of these Raptor shocks is the polished and black anodized aluminum components. They offset the matte Cerakote finish for a subtle yet bold statement. These Dirt Logic 3.0 Bypass shocks are the pinnacle of shock performance for the most aggressive offroad conditions. Features: 3.0in Black Cerakote Body 120 Hour Salt Spray. 3 Tube design with 2 compression and
Located in Chino, California our headquarters spans across five acres. The custom building was constructed to Fabtech's specification for in house development, manufacturing, distribution and administration. The 100,000 square foot facility is divided into designated departments that can operate as a single unit or collectively as a group. This allows Fabtech to function 24 hours a day as needed without compromising security, capacity or quality of the operations. Fabtech's development capabilities are second to none with over 25 years of experience in aftermarket suspension design. State of the art software, fabrication equipment along with our seasoned engineers and fabricators allow the company to develop products that are constantly on the cutting edge. Fabtech has received numerous awards for our designs that continue to lead the market. Proper design in suspension development is key in providing a quality, trouble free product to the end consumer. Fabtech leads the industry with extensive research, design technology and rigorous testing that results in the highest performing, finest quality suspension system for the discerning offroad enthusiast. New vehicle platforms now require a full integration of the vehicles electronics and sensors into the suspension design in order for the vehicle to properly function. Fabtech has invested into proprietary development processes and technologies to aid in properly designing new vehicle suspension systems that lead the industry. To ensure product quality, Fabtech builds all of its componentry in house. The manufacturing division is a world class lean environment dedicated to consistently producing quality parts in low or high volume production runs. Multiple laser cutters, robotic welders, forming equipment, machining centers and skilled welders provide flexibility and quality to its production. Packaging, warehousing and distribution are contained within the building for immediate shipment worldwide.
