Edelbrock E-Force Supercharger Kit #1585 with 2.75" pulley on 91 octane pump gas Engine Specs: Stock 4.6L block, Kellogg 3.8" stroke forged steel crankshaft, Manley 5.85" forged steel H-Beam rods, CP forged Aluminum pistons, stock cylinder heads ported by EEI, Comp Cams VSR "Serious Street" camshafts and BHJ SFI-Approved 7.5" Damper and 8.9:1 compression produced 646 HP and 646 FT/LBs at 13-14 psi of boost.
Edelbrock E-Force Competition Supercharger kit #1585 includes all of the essential components that a racer or tuner shop would need to build a custom supercharger for racing applications. Our competitors kits often require that you buy a complete system and then remove the components that would not be utilized on a custom build. The Edelbrock E-Force Competition kit #1585 gives you the option of choosing the equipment you want when building a custom supercharged Mustang. This kit includes the essential supercharger package components with selectable options based on your purpose built needs - from our Competition Air Intake System #15808 to fuel injectors (available in 41 lb/hr and 60 lb/hr), pulleys (available in 3.5", 3.25", 3.0" and 2.75") and much more. Finally, finish off your custom installation with a set of Edelbrock E-Force Coil Covers #41133. These covers are black powdered coated for durability with contrast machined fins and the Edelbrock logo for a clean look. We are confident that our E-Force Supercharger Systems will provide the best performance at a competitive price. Our systems are also easy to install and are the quietest on the market today. Each system is backed by Edelbrock's exceptional customer service and superior quality.
Attention Professional Tuners and Installers!
Our competitive pricing allows you the opportunity to configure a high horsepower custom tailored package to your customers. A kit could consist of our Competition kit #1585, Competition Air Intake System #15808, injectors and pulley of your choice, a GT500 fuel pump kit from FRPP, and your own tune.
E-Force Competition Kit Includes
√ Supercharger Manifold Assembly (Featuring Eaton TVS Rotors)
√ 3.25" Pulley
√ 60lb Injectors
√ 85mm Electronic Throttle Body
√ Cast Aluminum Alternator/Idler Bracket
√ Steel belt tensioner brace
√ Cast Aluminum Water Crossover
√ Dual Core Low Temp. Heat Exchanger for Intercooler System |
√ Electric Intercooler Water Pump
√ Intercooler Recovery Tank
√ -12 AN Intercooler Fittings
√ Steel Idler Pulleys With Heavy Duty High Speed Bearings
√ All The Necessary Mounting Hardware
√ All The Necessary Wiring & Plumbing |
Features and Benefits:
- Installs under the stock hood while maintaining factory accessories
- 2300cc (140 cubic inch) Eaton® TVS® GEN VI rotor assembly
- Unique intake manifold design with 15" long runners (Increased low-end torque)
- 100,000 mile self-contained oiling system
- Customers have acheived over 800 HP using this kit
- For off-road competition and racing use only
- Made in USA for absolute quality and performance
