Details
SPECS
fasteners: 3/8" ARP 2000
torque: 43 ftlbs with ARP moly lube on threads
pin fit: bushed
recommended up to 750 HP
DIMENSIONS
length: 5.850 in.
rod journal: 1.889 in.
housing bore: 2.0080 in.
pin size: 0.866 in.
big end width: 0.9350 in.
pin end width: 0.9350 in.
thickness above pin: 0.210 in.
typical weight: 550g
RECOMMENDED BEARINGS
Clevite CB1780
NOTES:Must be used with stroker crankshaft and pistons
